High Cavity Manifold Systems
High cavity single or multi-level systems
Mastip's expert teams can design and manufacture high cavity single or multi-level systems, with thermal or valve gates. Our systems are designed and manufactured to the highest level of quality, delivering a uniform melt to each nozzle, ensuring cavity-to-cavity consistency. This is achieved through natural balancing of the flow channels and ensuring constant temperature profiles are maintained across the manifold block. Mastip can provide you with a Manifold system to meet your requirements in standard high quality mould base steel or stainless steel plates.
Technical Information
-
Designed, Manufactured and Tested
Every high-cavity manifold goes through extensive design and analysis to ensure the following:
- optimized melt delivery
- balanced cavity-to-cavity filling
- excellent gate quality
- optimized thermal profile
-
Incorporating M-Series Multi-Cavity Nozzles
Specifically designed for multi-cavity systems, the MX and MJ nozzle series are simple to install, front-loading for ease of servicing and ideal for close-pitch gating due to small gate pocket rquirements.
MX and MJ nozzles have superior thermal insulation and precise temperature control to optimise cycle times and are available in sizes ranging from 45-175 mm.
-
Guaranteed to Perform
Mastip Hot Half systems are backed by a 3 year leak-proof guarantee, available in thermal or valve gate configurations and delivered as a complete solution to integrate seamlessly into your mould.
Include a Meticom Temperature Controller with your Hot Half System order and we will extend the warranty on the Mastip Hot Half System from 3 to 5 years.
Product Information
You can download the datasheets for the catalogue as a PDF here. Please fill out your details to download the files.
